Get a Quote

Promotion Rules

* Find a distributor in your country or contact us directly to enjoy the offer.

* This offer is only valid for the first 200 units.

* This promotion is only for the KILOVIEW P series at this time; other series products are not included.

* If you have any questions or issues, don’t hesitate to get in touch with us at [email protected]

Play Video

Live Streaming Anytime Anywhere

*Free KiloLink bonding software with remote management for preview and status checking
*Reliable connection with ABR and bandwidth balance
*4×4G-LTE and WiFi bonding
*Direct streaming via SRT, RTSP, RTMP, and TS-UDP
*Voice intercom, PTZ, and Recording
*Easy to get back to SDI or HDMI via DC230 and D300

Up to 5 Connections Bonding, Stream Like a Pro

2x Internal 4G Cellular + 2x USB 4G Cellular (LAN)+ 1x Wi-Fi (+1*RJ45) supported and it’s free configurable of any desired network.

With the patented bonding algorithm with KiloLink, P series encoders can automatically balance the data of all connections and adjust the bitrate accordingly to make sure the reliable streaming.

Besides, P series can support Wi-Fi hotspots for data and file transmission.

Applications

Outdoor streaming, remote video production, IRL streaming, news interviewing, emergency conducting, mobile video transmission, cloud video transmission, hospital video transmission and more wireless video transmission situations.

Kiloview P series 4G bonding encoder application diagram
Wireless-NDI-Video-Encoder-kiloview-n1-n2-720P-streaming

Outdoor Live Streaming

kiloview-product-application-SRT-Remote-Transmission
SRT Remote Transmission
kiloview-product-application-Program-Production-Monitoring

Program Production & Monitoring

kiloview-product-application-Audio-Video-Engineering
Audio/Video Engineering

Parameters

Model No.P1, P2
InputSDI (P1): HDMI (P2)
Transmission mode 4G-LTE, WIFI (2.4/5G dual band), Ethernet by USB expansion
4G bonding capacity4 channels of 4G bonding (2 CH internal+ 2 CH external)
Video resolutionUp to 1080P60Hz:
1080p23.98/24/25/29.97/30
1080p50/59.94/60
1080i50/59.94/60
720p23.98/24/25/29.97/30
720p50/59.94/60
Video encodingH.264/AVC, Motion-JPEG
Audio encodingAAC/G.711
Encoding latency<67ms
Media protocolRTMP/RTSP/SRT/RTP/HLS/TS over UDP, custom for SIP
Graphic overlayUser-defined text, image overlay
RecordingTF card slot/hard disk by USB expansion for local recording and NAS network storage
ManagementAndroid APP/Web
Hot shoeRemovable
Battery capacity3.7V 6800mAh (29.6Wh)
Power supplyDC 12V 1A
Power consumption6.5w
Operating temperature-20~45℃
Dimension115*75*35mm (4.53”*2.95”*1.38”)
Weight400g (14 oz)
DownloadsDocs & Firmware

Related Products

S2 H.265 4K Encoder
HDMI 2.0 SRT/NDI|HX, with Intercom
G1/G2 H.264 Wireless Encoder
Wi-Fi/USB Extended 4G / Wired Transmission
P1/P2 H.264 4G Bonding Encoder
SDI/HDMI Input, 4x4G Network Bonding
E1/E2 H.264 Wired Encoder
SDI/HDMI Input/Loop, SRT Supported
SDI/HDMI Rackmount Codec
Mixed Insertion 4/8/16 Channels, Dual Power
M2 H.264 Dual Port Encoder
HDMI+VGA Input, 1080P 60Hz Supported

Quick Comparison of our Encoders

Product TypeModel No. Input InterfaceNetwork ConnectionsResolutionRemark(s)
H.265 4K EncoderS2HDMIEthernet/Satellite4KP60
H.264 4G EncoderP13G-SDI4G/WiFi/Ethernet/Satellite1080P60Built-in Battery, Cold-shoe Installation, Compatible with Outdoor Activities
P2HD HDMI4G/WiFi/Ethernet/Satellite1080P60Built-in Battery, Cold-shoe Installation, Compatible with Outdoor Activities
Rackmount Codec1U-1/2/3/43G-SDI +HDMIEthernet/Satellite1080P60Mixed Insertion of 1-4 Channels of Codec Modules, Dual Power
3U-1/8/163G-SDI +HDMIEthernet/Satellite1080P60Mixed Insertion of 8/16 Channels of Codec Modules, Dual Power
H.264 Wireless EncoderG13G-SDIWiFi/Ethernet/USB Extended 4G/Satellite1080P60
G2HD HDMIWiFi/Ethernet/USB Extended 4G/Satellite1080P60
H.264 Wired EncoderE13G-SDIEthernet/Satellite1080P60
E2HDMIEthernet/Satellite1080P60
M2VGA+HDMIEthernet/Satellite1080P60
