| Name | Color | Status | Description |
|---|---|---|---|
| POWER | White | Always on | Power connected |
| Flashing | Device failure | ||
| Off | No power supplied or device failure | ||
| RUN | White | Flashing | Device is working |
| Off | The device is abnormal or not started | ||
| SIGNAL LOCK | White | Always on | Video signal inputting locked |
| Flashing | Video signal outputting unlocked | ||
| Off | No video signal connected or inputting is abnormal |
Tally light
When the NDI source is output to NDI receivers (such as vMix, TriCaster, etc.) and switching Program to Preview, the receives the notification and changes the color on the "Tally", shown as below:
