The NDI protocol is a high-performance standard that enables anyone to use real-time, ultra-low-latency video on existing IP video networks.
Besides NDI|HX2, N1/N2 supports full range protocols including RTSP, RTMP, RTMPS, RTP, SRT, HLS, TS-UDP, Onvif, live stream with RTMP/RTMPS, while live production with NDI|HX and remote production with SRT, all can be handled at the same time.
It also supports ONVIF 1.1/2.0 for easy access to security protection system/ NVR system.
TV programming, Online courses, Online training, Remote pathology, Conferences, Concerts, and so on.
|Transmission mode||Enhanced WIFI, Ethernet by USB expansion|
|Media protocol||NDI-HX/RTSP/RTMP/SRT/HLS/TS over UDP|
|Video resolution||Up to 1080P60Hz:
|Video encoding||H264/AVC, Motion-JPEG|
|Latency||Using NDI protocol for end-to-end latency by Ethernet is about 150ms|
|Graphic overlay||Support custom text, image overlay function, and superimposed to any position on the screen|
|Management||Web UI and remote management with KILOVIEW KiloLink Server|
|Audio Intercom||Supported (KV Apps Required)|
|Recording||Micro SD/TF card slot, local recording, NAS network storage|
|Battery capacity||3.7V 6800mAh (29.6Wh)|
|Power supply||DC 12V 1A|
|Support Downloads||Docs & Firmware|
|Product Type||Product No.||NDI Codec Capability||Video I/O Connectivity||Resolution||Notes|
|N6||NDI High Bandwidth/NDI|HX||HDMI||1080P60|
|N5||NDI High Bandwidth/NDI|HX||3G-SDI||1080P60|
|N50||NDI High Bandwidth/NDI|HX||12G-SDI||4KP60|
|N60||NDI High Bandwidth/NDI|HX||HDMI||4KP60|
|N3||NDI High Bandwidth||3G-SDI||1080P60|
|N30||NDI High Bandwidth||12G-SDI||4KP60|
|N40||NDI High Bandwidth||HDMI||4KP60|
|NDI Wireless Encoder||N1||NDI|HX||SDI||1080P60||WiFi supported, Battery Builld-in|
|N2||NDI|HX||HDMI||1080P60||WiFi supported, Battery Builld-in|
|NDI Encoder||E3||NDI|HX||SDI+HDMI||4KP30 in HDMI, 1080P60 in SDI|
|U40||NDI High Bandwidth/NDI|HX||HDMI||4KP60|
|NDI Decoder||D350||NDI High Bandwidth/NDI|HX||SDI+HDMI||4KP60|
