H.264 HD SDI/HDMI Encoder

Professional while Affordable streaming Encoder

H.264 HD SDI/HDMI Encoder

Professional while Affordable streaming Encoder
HDMI-encoder-kiloview-e-series-product-portrait

Stable Video Encoder for Live Streaming

Kiloview E series wired hardware video encoder converts SDI/HDMI base-band video to H.264 IP streams, to achieve remote video transmission or live across internet WAN or over local network LAN. They support the most common protocols including SRT, RTMP, RTMPS, RTP, HLS, UDP, RTSP, Onvif, and are widely applied to professional live production, streaming, broadcasting, etc.

E1: SDI Input/Loop;
E2: HDMI Input/Loop

Features

Stream Directly to YouTube

You can send your encoded video to live streaming platforms like YouTube or Twitch in the device web console.

Before streaming with our HD hardware encoder, you can edit config on stream settings (such as H.264 profile, bitrate level, frame rate, GOP, overlay, and so on) and protocol settings (such as YouTube streaming URL and key).

The E series live streaming encoder is equipped with powerful chipsets, therefore, you will have a stable 24/7 stream at lower power consumption.

HDMI to H.264 Encoding

The E1/E2 encoder takes SDI/HDMI video source from your camera or any video device and encode it into H.264 stream.

You can start your live stream using your camera, as long as it's connecting to our encoder by SDI/HDMI.

The video is automatically compressed and encoded into H.264 IP stream.

You will get a smooth experience with video taking, data encoding, and stream distribution.

Real-time Live Streaming

Compared with software encoding solutions, Kiloview encoders works more efficiently on latency and video quality.

Whether streaming to the public streaming platform or syncing video data with another counterpart, the video latency is always perfect for your broadcasting and end-to-end communication.

The measured latency for SRT protocol encoding is less than 67ms, and the end-to-end connection is less than 1s.

So, you will have "real-time" live streaming with E1/E2.

Real HD 1080P60 Video Supported

It supports reali HD video input with resolution up to 1920*[email protected] to ensure that the image quality is perfect.

Low Latency, High-Quality Streaming

E series adopt standard H.264 coding algorithm, so they ensure high-quality image and smooth live streaming. They provide you superior video with low-latency, low bitrate and low bandwidth.

icon-low-latency

Encoding delay ≤ 67ms

icon-adjustable-bitrate

Adjustable bitrate 64kbps~40Mbps

icon-low-bandwidth

Low bandwidth [email protected]

(Note: the actual delay condition is also related to your Internet status)

Low Latency, High-Quality Streaming

E series adopt standard H.264 coding algorithm, so they ensure high-quality image and smooth live streaming. They provide you superior video with low-latency, low bitrate and low bandwidth.

(Note: the actual delay condition is also related to your Internet status)

It’s a recorder and an interphone!

Recording prepares for future. Kiloview E series provides simultaneous recording while you are doing live streaming to many media destinations. And redundant recording is realized with Micro SD/TF/USB/NAS with recording files in the format of .ts, .mp4, .mov,.mkv, avi.

It also supports SDI/HDMI embedded and 3.5mm analog audio coding, so you can use KILOVIEW voice intercom software to realize real-time voice intercom. >Learn more

It’s a recorder and an interphone!

Recording prepares for future. Kiloview E series provides simultaneous recording while you are doing live streaming to many media destinations. And redundant recording is realized with Micro SD/TF/USB/NAS with recording files in the format of .ts, .mp4, .mov,.mkv, avi.

It also supports SDI/HDMI embedded and 3.5mm analog audio coding, so you can use KILOVIEW voice intercom software to realize real-time voice intercom. >Learn more

All IP Video Protocols Supported

E series supports full range of protocols including RTSP/ RTMP/ RTMPS/ SRT/ HLS/ TS-UDP/ Onvif, that means live stream with RTMP/RTMPS, while remote production with SRT, all can be handled at the same time. It also supports ONVIF 1.1/2.0 for easy Access To Security Protection System / NVR System
HDMI-encoder-kiloview-e-series-multiple-protocols-supported-fixed-0524

Encoding & Streaming to Multiple Platforms

You can set dual stream output (main stream and sub stream) in the built-in web console. Each stream can be used to up to 8 platforms with the same or different protocols, altogether it can simultaneously live stream to up to 16 platforms. Main stream resolution up to 1080p60Hz, sub stream resolution up to 720p 60Hz.

HDMI-encoder-kiloview-e-series-multi-platform-foreground

Encoding & Streaming to Multiple Platforms

You can set dual stream output (main stream and sub stream) in the built-in web console. Each stream can be used to up to 8 platforms with the same or different protocols, altogether it can simultaneously live stream to up to 16 platforms. Main stream resolution up to 1080p60Hz, sub stream resolution up to 720p 60Hz.

HDMI-encoder-kiloview-e-series-dual-stream-mobile-final-0923

Let’s go Social

With FPGA processing unit, it can easily realize the functions of rotating and cropping for vertical/horizontal video which makes it social media friendly.

LOGO/ Image/ Text Overlay

Add any self-defined text, time and image overlay at any position to announce your copyrights and have fun!

HDMI-encoder-kiloview-e-series-horizontal-vertial-conversion

7x24h Operation

Portable and low power consumption makes it 24 hours continuous working available.





Application

TV programming, lecture capture, online courses, remote learning, course recording, broadcast meetings, Web training, remote pathology, telemedicine, conferences, concerts, sports

HDMI-encoder-kiloview-e-series-application-chart-new-0521

More Highlights

Embedded Audio

SDK/API Development

3.5mm Analog Audio Input

High-end Chip

Real-time Loop

Web-Based Interface

USB-extended PTZ

7 * 24h Operation

Parameters

ModelE1(SDI)/E2(HDMI)
Video inputE1: 1*BNC 3G-SDI; E2: 1*HDMI
Analog audio interface2*3.5mm
USB interface2*USB 2.0 Type-A
Micro SD1*Micro SD/TF card storage interface
Network supportWired/Satellite
Video loopE1: 1*BNC 3G-SDI; E2:1*HDMI
Video resolution
Up to 1080P60Hz:
SDI: 1080P23.98/24/25/29.97/30Hz;1080P50/59.94/60Hz;
1080i50/59.94/60Hz;720P23.98/24/25/29.97/30Hz;720P50/59.94/60Hz
HDMI: 1080P23.98/24/25/29.97/30Hz;1080P50/59.94/60Hz;
1080i50/59.94/60Hz;720P30/50/59.94/60Hz; below 1920*1200.
Video encodingH.264/AVC, Motion-JPEG
Audio encodingAAC/G.711
Encoding latency<67ms
Media transmission protocolsSRT/RTMP/RTP/RTMPS/HLS/TS over UDP/RTSP
Image and text overlaySupport
Record storageMicro SD/TF card local recording, and NAS network storage
ManagementAPP/ Web
Power supply/consumptionDC 12V 1A/4W
Operation temperature-20℃~60℃
Dimension125*89*28mm (4.92”*3.50”*1.10”)
Weight380g (13.4oz)
DownloadsDocs & Firmware

FAQ about Kiloview E Series Video Encoder

Q: What does an SDI/HDMI video encoder do, and why do we need it?

A: You can not send your video directly from the camera to the Internet because the raw video data is huge and can easily reach the Internet data limit.

Therefore, if we want to stream our video from SDI/HDMI camera to a public platform, we must compress the data and convert it into a common IP stream. That is the task of a video encoder.

You are streaming with a mobile phone or computer in most cases, so you do not probably notice that. While for professional video production & streaming, an encoding system is important for the work.

Q: How much is the SDI/HDMI encoder?

A: We have a distribution network across the globe. For detailed price information or service terms of our products, please check from our local partners near you: https://www.kiloview.com/en/buy/

At the same time, you can contact [email protected] for more directions.

Q: How to set YouTube, Facebook, Twitch streaming in the encoder?

A: After logging in the device web panel, go to “Encoding & Stream,” “Encoding & Stream Settings,” in the H.264 mainstream section, add an RTSP stream, and put in the stream URL and stream key from Youtube, Facebook, Twitch.

You can go to the specific platform and find them in the stream settings to get the stream information.

Q: What’s the difference between hardware encoder and software encoder (like OBS)?

A: Software encoding uses the CPU (normally your PC or mobile phone) to encode the video. In contrast, hardware encoding is mainly based on GPU (graphics processing unit) to process video data instead of CPU.

Both are OK for stream beginners, but for professional video production, we recommend using hardware encoders for their high efficiency and stability.
